Stihl HT 75 - Page 18

HT 75
English
16
To open:
N Open the bracket
N Twist fuel cap (ca. 1/4 turn)
Markings on fuel cap and oil tank must
align
N Remove the fuel cap
Filling up with chain oil
N Fill up with chain oil
Take care not to spill chain oil during
refilling and do not overfill the tank.
STIHL recommends use of the STIHL
filling system for chain oil (special
accessory).
To close:
Clip is in an upright position:
N Fit the fuel cap – marks on the fuel
cap and oil tank must line up.
N Push the fuel cap down as far as it
will go
N Hold the fuel cap down and twist it
clockwise until it engages
Then the markings on fuel cap and oil
tank will align
N Close the bracket lock
0000,GXX-0135-A0 KN
0000-GXX-0136-A0
0000-GXX-0137-A0 KN
0000-GXX-0138-A0 KN
0000-GXX-0137-A0 KN
0000-GXX-0139-A0 KN
0000-GXX-0140-A0 KN
0000-GXX-0141-A0 KN
