39FC 75, FC 85, FH 75, FS 75, FS 80, FS 85, HL 75, KM 85, KW 85
: Pull the throttle cable out of the
tensioner.
VA
936RA117
: Pull short circuit wire’s connector
(arrow) off the tag on the ignition
module.
VA
936RA118
: Take throttle cable’s protective
tube out of the retainer.
– Remove the throttle trigger, b
8.6.1
: Lift the contact spring (1) and
remove the throttle cable (2).
Install in the reverse sequence.
: Make sure the throttle cable (1),
contact spring (2), protective
tube (3) and insulator (4) are
properly seated.
Check that the short circuit wire
(arrow) is making good contact.
