Stihl MS 181 C-BE User Manual

Drawing E Rewind starter ErgoStart/Easy2Start
Reference Item number Qty Description
(1) MS 181, (2) MS 181 C-BE, (3) MS 181-Z, (4) MS 181 C-BE Z
MS 181, MS 181 C
10
SCS 01-2010 3.29
1139 080 2103 1 Fan housing with rewind starter (2,4)
 1 - 16
1 1139 080 1803 1 Fan housing (2,4)
 2
2 1110 084 9102 1 Bushing (2,4)
3 1123 190 0600 1 Rewind spring (2,4)
4 1123 195 0401 1 Rope rotor (2,4)
5 1121 195 3400 1 Starter grip (2,4)
6 4137 195 8200 1 Starter rope Ø 2.7x910 mm (2,4)
0000 930 2281 1 Starter rope Ø 2.7 mm x 30.8 m (A,B) (2,4)
7 0000 958 0923 1 Washer (2,4)
8 1123 195 7200 2 Pawl (2,4)
9 1128 195 3500 1 Spring (2,4)
10 1123 195 9001 1 Washer (2,4)
11 1139 190 0700 1 Spring housing (2,4)
12 1139 195 2000 1 Carrier (2,4)
13 0000 958 0806 1 Washer (2,4)
14 9455 621 0570 1 Circlip 8x0.8 (2,4)
15 1139 084 7800 1 Segment (2,4)
16 1139 967 1502 1 Model plate MS 181 C (2,4)
17 9074 477 4135 3 Pan head self-tapping screw IS-P5x20 (2,4)
18 9074 477 4139 1 Pan head self-tapping screw IS-P5x25 (2,4)

Stihl MS 181 C-BE Specifications

General

Engine Power	1.5 kW (2.0 bhp)
Vibration Level (Left/Right)	3.5/3.5 m/s²
Displacement	31.8 cm³
Fuel Capacity	9.1 oz (270 cc)
Bar Length	16 in.
Oilomatic Chain Pitch	3/8" PM3
Powerhead Weight	9.7 lbs (4.4 kg)
