Drawing F Ignition system
Reference Item number Qty Description
(1) MS 181, (2) MS 181 C-BE, (3) MS 181-Z, (4) MS 181 C-BE Z
MS 181, MS 181 C
12
SCS 01-2010 3.29
1 1139 400 1201 1 Flywheel (1,3) (25.2005)
2 0000 955 0802 1 Collar nut M8x1
3 1139 400 1203 1 Flywheel (2,4) (25.2005)
 4 - 6
4 1139 195 7200 2 Pawl (2,4)
5 0000 998 1100 2 Torsion spring (2,4)
6 9460 624 0320 2 E-clip 3.2 (2,4)
7 1139 400 1307 1 Ignition module
 8, 9
8 0000 405 1003 1 Spark plug boot
9 0000 998 0618 1 Torsion spring
10 9075 478 3018 2 Pan head self-tapping screw IS-D4x18
11 9291 021 0100 1 Washer 4.3
12 1139 405 8000 1 Insulator
13 1139 448 1200 1 Lead retainer
14 1139 440 3000 1 Wiring harness

Stihl MS 181 C-BE Specifications

General

Engine Power	1.5 kW (2.0 bhp)
Vibration Level (Left/Right)	3.5/3.5 m/s²
Displacement	31.8 cm³
Fuel Capacity	9.1 oz (270 cc)
Bar Length	16 in.
Oilomatic Chain Pitch	3/8" PM3
Powerhead Weight	9.7 lbs (4.4 kg)
