Drawing G Hand guard, Chain brake
Reference Item number Qty Description
(1) MS 181, (2) MS 181 C-BE, (3) MS 181-Z, (4) MS 181 C-BE Z
MS 181, MS 181 C
14
SCS 01-2010 3.29
1 1139 792 9100 1 Hand guard
2 1121 160 5000 1 Lever
3 1123 162 7800 1 Flat spring
4 0000 958 0521 1 Washer
5 1123 162 5800 1 Strap
6 9460 624 0400 1 E-clip 4
7 1139 160 5400 1 Brake band
8 1139 162 7900 1 Tension spring
9 1139 021 1100 1 Cover
1139 160 2000 1 Clutch
 10 - 13
10 1121 162 3201 1 Carrier
11 1139 162 0800 3 Clutch shoe
12 1127 162 3000 3 Retainer
13 0000 997 5600 3 Tension spring
14 1121 162 1001 1 Cover washer
15 1123 640 7102 1 Worm
 16
16 1123 647 2400 1 Spring
17 1123 640 2073 1 Chain sprocket 3/8" Picco 6T
18 9512 933 2260 1 Needle cage 10x13x10
19 0000 958 1022 1 Washer Ø 27 mm
20 9460 624 0801 1 E-clip 8x1.3
1123 007 1000 1 Chain tensioner kit (B) (1,3)
 21 - 25
21 1123 007 1004 1 Spur gear / chain adjusting screw kit (1,3)
22 1123 640 1900 1 Tensioner slide (1,3)
23 1123 664 1400 1 Thrust pad (1,3)
24 1123 664 2200 1 Cover (1,3)
25 9075 478 3015 1 Pan head self-tapping screw IS-D4x15 (1,3)
26 1123 664 0500 1 Bumper spike (1,3)
27 9075 478 4115 2 Pan head self-tapping screw IS-D5x16 (1,3)
28 1139 640 1700 1 Chain sprocket cover (1,3)
29 0000 955 0801 1 Hexagon nut M8 (1,3)
30 0000 967 3630 1 Instruction label (3,4) USA
31 1139 650 7700 1 Chain catcher (20.2007)
 32, 33
32 9062 319 1270 1 Countersunk screw M6x14 (20.2007)
33 9214 320 0900 1 Lock nut M6 (20.2007)

Stihl MS 181 C-BE Specifications

General

Engine Power	1.5 kW (2.0 bhp)
Vibration Level (Left/Right)	3.5/3.5 m/s²
Displacement	31.8 cm³
Fuel Capacity	9.1 oz (270 cc)
Bar Length	16 in.
Oilomatic Chain Pitch	3/8" PM3
Powerhead Weight	9.7 lbs (4.4 kg)
