Drawing J Air filter, Manifold
Reference Item number Qty Description
(1) MS 181, (2) MS 181 C-BE, (3) MS 181-Z, (4) MS 181 C-BE Z
MS 181, MS 181 C
18
SCS 01-2010 3.29
1 1139 120 1602 1 Air filter, fleece
2 1139 120 1601 1 Air filter (B)
3 1139 120 3401 1 Filter base
 4, 5
4 1139 791 5900 2 Stop buffer
5 9646 945 0610 1 O-ring 8x1.6
6 9074 477 4135 3 Pan head self-tapping screw IS-P5x20
7 1139 121 6900 1 Baffle
8 9216 261 0700 2 Hexagon nut M5
9 1139 120 0605 1 Carburetor C1Q-S121B (1,3)
10 1139 120 0606 1 Carburetor C1Q-S122B (2,4)
11 1139 120 0900 1 Carburetor bracket
12 1139 141 1801 1 Sleeve
13 1139 140 2500 1 Manifold
14 9075 478 3012 4 Pan head self-tapping screw IS-D4x12

Stihl MS 181 C-BE Specifications

General

Engine Power	1.5 kW (2.0 bhp)
Vibration Level (Left/Right)	3.5/3.5 m/s²
Displacement	31.8 cm³
Fuel Capacity	9.1 oz (270 cc)
Bar Length	16 in.
Oilomatic Chain Pitch	3/8" PM3
Powerhead Weight	9.7 lbs (4.4 kg)
