Stihl MS 181 C-BE - Carburetor C1 Q-S122 B Components

Drawing L Carburetor C1Q-S122B
Reference Item number Qty Description
(1) MS 181, (2) MS 181 C-BE, (3) MS 181-Z, (4) MS 181 C-BE Z
MS 181, MS 181 C
24
SCS 01-2010 3.29
1139 120 0606 1 Carburetor C1Q-S122B (2,4)
 1 - 40
1 1139 121 5400 1 Valve jet (2,4)
2 4116 121 5100 1 Inlet needle (2,4)
3 1132 121 5603 1 Fixed jet 0.50 (2,4)
4 4128 122 3000 1 Spring (2,4)
5 1125 121 5000 1 Inlet control lever (2,4)
6 1120 121 9200 1 Spindle (2,4)
7 1120 122 6600 1 Collar screw (2,4)
8 4229 129 0901 1 Gasket (2,4)
9 4229 121 4700 1 Metering diaphragm (2,4)
10 1139 120 0801 1 End cover (2,4)
 11 - 15
11 1139 120 7300 1 Air valve shaft with lever (2,4)
12 1139 122 3200 1 Torsion spring (2,4)
13 4282 122 9000 1 E-clip (2,4)
14 1139 126 0300 1 Air valve (2,4)
15 1125 122 7402 1 Round head screw (2,4)
16 1120 122 6601 4 Collar screw (2,4)
17 1139 120 9700 1 Pump piston kit (2,4)
18 1139 121 3300 1 Throttle shutter (2,4)
19 1125 122 7403 1 Round head screw (2,4)
20 1139 122 6800 1 Low speed adjustment screw (2,4)
21 1139 122 6700 1 High speed adjustment screw (2,4)
22 4229 121 2701 1 Cap (2,4)
23 1123 121 7800 1 Strainer (2,4)
24 1125 122 4200 1 Ball (2,4)
25 1123 121 2904 1 Choke shutter (2,4)
26 1129 121 4800 1 Pump diaphragm (2,4)
27 1123 129 0905 1 Gasket (2,4)
28 1139 121 0800 1 End cover (2,4)
29 1120 122 7800 1 Oval head screw (2,4)
30 1139 120 7200 1 Choke shaft with lever (2,4)
31 1139 122 3202 1 Torsion spring (2,4)
