Stihl MS 181 C-BE - Page 26

Drawing L Carburetor C1Q-S122B
Reference Item number Qty Description
(1) MS 181, (2) MS 181 C-BE, (3) MS 181-Z, (4) MS 181 C-BE Z
MS 181, MS 181 C
24
SCS 01-2010 3.29
32 1139 120 7100 1 Throttle shaft with lever (2,4)
 33
33 1139 122 7101 1 Screw (2,4)
34 1139 122 3201 1 Torsion spring (2,4)
35 4282 122 9000 2 E-clip (2,4)
36 1139 121 3501 1 Throttle lever (2,4)
37 1139 122 3203 1 Torsion spring (2,4)
38 1139 121 3502 1 Throttle lever (2,4)
39 9079 319 0280 1 Flat head screw M3x3.5 (2,4)
40 1139 122 6200 1 Idle speed adjustment screw (2,4)
4229 007 1060 1 Set of carburetor parts (2,4)
 8, 9, 26, 27
