Stihl MS 181 C-BE User Manual

Drawing D Rewind starter
Reference Item number Qty Description
(1) MS 181, (2) MS 181 C-BE, (3) MS 181-Z, (4) MS 181 C-BE Z
MS 181, MS 181 C
8
SCS 01-2010 3.29
1139 080 2102 1 Fan housing with rewind starter (1,3)
 1 - 11
1 1139 080 1802 1 Fan housing (1,3)
 2
2 1110 084 9102 1 Bushing (1,3)
3 1129 190 0601 1 Rewind spring (1,3)
4 1123 195 0400 1 Rope rotor (1,3)
5 1125 195 7200 1 Pawl (1,3)
6 0000 958 0923 1 Washer (1,3)
7 1118 195 3500 1 Spring (1,3)
8 1121 195 3400 1 Starter grip (1,3)
9 0000 195 8203 1 Starter rope Ø 3x850 mm (1,3)
10 1139 084 7800 1 Segment (1,3)
11 1139 967 1501 1 Model plate MS 181 (1,3)
12 9074 477 4135 3 Pan head self-tapping screw IS-P5x20 (1,3)
13 9074 477 4139 1 Pan head self-tapping screw IS-P5x25 (1,3)
14 0000 190 3402 1 Starter grip ElastoStart Ø 3 mm (B) (1,3)
 15, 16
15 0000 195 8200 1 Starter rope Ø 3x800 mm (B) (1,3)
16 0000 195 7001 1 Cap (B) (1,3)
1139 007 1001 1 Cover plate kit (B) (1,3)
 17, 18
17 1139 084 8200 1 Cover plate (B) (1,3)
18 9099 021 2770 2 Self-tapping screw 3.9x13 (B) (1,3)

Stihl MS 181 C-BE Specifications

General

Engine Power	1.5 kW (2.0 bhp)
Vibration Level (Left/Right)	3.5/3.5 m/s²
Displacement	31.8 cm³
Fuel Capacity	9.1 oz (270 cc)
Bar Length	16 in.
Oilomatic Chain Pitch	3/8" PM3
Powerhead Weight	9.7 lbs (4.4 kg)
