MS 171, MS 171 C, MS 181, MS 181 C, MS 211, MS 211 C
English
20
N Remove screw (2)
N Position tensioning gear (1) and
guide bar (3) relative to one another
N Insert and tighten screw (2)
Releasing the chain brake
N Pull hand guard towards the front
handle until it engages audibly –
chain brake is released
Fitting the saw chain
WARNING
Put on protective gloves – risk of injury
by the sharp cutters.
N Fit the saw chain – starting at the
nose of the guide bar – pay attention
to the position of the tensioning gear
and the cutting edges
N Turn tensioning gear (1) to the right
as far as possible
N Turn the guide bar so that the
tensioning gear faces the user
N Place the saw chain on the chain
sprocket (2)
N Slide the guide bar over the collar
screw (3); the head of the rear collar
screw must protrude into the oblong
hole
