Stihl MS 211 Instruction Manual

MS 171, MS 171 C, MS 181, MS 181 C, MS 211, MS 211 C
English
50
Rollomatic E Light and Rollomatic E
guide bars
Saw chains 3/8"Picco
Chain sprocket
The average chain speed during
operation is normally approx. 20% less
than the maximum chain speed to
ISO 11681. Contact the STIHL dealer
when selecting the personal protective
equipment.
Noise and Vibration Data
For further details on compliance with
Vibration Directive 2002/44/EC see
www.stihl.com/vib.
Sound pressure level L
p
to ISO 22868
Sound power level L
w
to ISO 22868
Vibration measurement a
hv,eq
to
ISO 22867
The K-factor in accordance with
Directive 2006/42/EC is 2.5 dB(A) for
the sound pressure level and sound
power level; the K-factor in accordance
with Directive 2006/42/EC is 2.0 m/s
2
for the vibration measurement.
REACH
REACH is an EC regulation and stands
for the Registration, Evaluation,
Authorisation and Restriction of
Chemical substances.
For information on compliance with the
REACH regulation (EC) No. 1907/2006
see www.stihl.com/reach.
Cutting lengths: 30, 35, 40 cm
Pitch: 3/8"P (9.32 mm)
Groove width: 1.3 mm
Sprocket nose: 9-tooth
Picco Micro 3 (63 PM3) Type 3636
Picco Duro 3 (63 PD3) Type 3612
Picco Super 3 (63 PS3) Type 3616
Pitch: 3/8"P (9.32 mm)
Drive link gauge: 1.3 mm
6-tooth for 3/8"P (spur chain sprocket)
Max. chain speed to
ISO 11681: 24.8 m/s
MS 171: 99 dB(A)
MS171C: 99dB(A)
MS 181: 100 dB(A)
MS 181 C: 100 dB(A)
MS 211: 100 dB(A)
MS 211 C: 100 dB(A)
MS 171: 112 dB(A)
MS 171 C: 112 dB(A)
MS 181: 112 dB(A)
MS 181 C: 112 dB(A)
MS 211: 113 dB(A)
MS 211 C: 113 dB(A)
Handle,
left
Handle,
right
MS 171: 4.0 m/s
2
4.5 m/s
2
MS 171 C: 3.5 m/s
2
3.5 m/s
2
MS 181: 3.5 m/s
2
3.0 m/s
2
MS 181 C: 3.5 m/s
2
3.0 m/s
2
MS 211: 3.5 m/s
2
3.5 m/s
2
MS 211 C: 3.5 m/s
2
3.5 m/s
2
