Stihl MS 250 User Manual

51MS 210, MS 210 C, MS 230, MS 230 C, MS 250, MS 250 C
English / USA
To reduce the risk of fire and burn
injury, use only spark plugs
authorized by STIHL. Always press
spark plug boot (2) snugly onto
spark plug terminal (1) of the proper
size. (Note: If terminal has
detachable SAE adapter nut, it must
be attached.)
A loose connection between spark
plug boot and ignition wire
connector in the boot may create
arcing that could ignite combustible
fumes and cause a fire.
: Remove the screws (1).
: Push the hand guard upward.
: Pull the underside of the fan
housing away from the crankcase
and remove it downward.
Versions with Easy2Start
1)
: Use circlip pliers to carefully remove
circlip (2).
: Remove the washer (3), driver (4),
spring housing (5) and washer (6).
If no suitable circlip pliers are available,
have the starter rope or rewind spring
replaced by your STIHL dealer.
1)
Special version
0
00BA036 TR
1
Replacing Starter Rope
and Rewind Spring
1
1
1
1
133BA014 KN
208BA012 KN
2
3
4
5
6

Stihl MS 250 Specifications

General

Engine Power	2.3 kW
Power output	2.3 kW
Displacement	45.4 cc
Weight	4.6 kg
Weight (without cutting equipment)	4.6 kg
Fuel Capacity	0.47 l
Fuel tank volume	0.47 l
Bar Length	40 cm
Chain Oil Capacity	0.20 l
Oil Capacity	0.20 l
Chain pitch	3/8"
