Stihl MS 441 Instruction Manual

MS 441
English
39
Erratic idling behavior, poor
acceleration (even though low speed
screw is open 1/4 turn)
N Idle setting is too lean: Turn the low
speed screw (L) counterclockwise
until the engine runs and
accelerates smoothly.
It is usually necessary to change the
setting of the idle speed screw (LA) after
every correction to the low speed
screw (L).
Fine tuning for operation at high
altitude
A slight correction of the setting may be
necessary if engine does not run
satisfactorily:
N Check the standard setting.
N Warm up the engine.
N Turn high speed screw (H) slightly
clockwise (leaner) – no further than
stop.
In some countries the muffler is
equipped with a spark arresting screen.
N If the engine is down on power,
check the spark arresting screen in
the muffler.
N Wait for the muffler to cool down.
N Take out the screw (1).
N Pull out the spark arresting
screen (2).
N Clean the spark arresting screen. If
the screen is damaged or heavily
carbonized, fit a new one.
N Refit the spark arresting screen.
N Insert the screw and tighten it down
firmly.
If engine is down on power, difficult to
start or runs poorly at idling speed, first
check the spark plug.
Fit a new spark plug after approx. 100
operating hours or earlier if the
electrodes are badly eroded.
Wrong fuel mix (too much engine oil in
the gasoline), a dirty air filter and
unfavorable running conditions (mostly
at part throttle etc.) affect the condition
of the spark plug. These factors cause
deposits to form on the insulator nose
which may result in trouble in operation.
Removing the spark plug
N Move the Master Control lever to the
stop position (0).
N Use the combination wrench to
open the fasteners (1) in the
direction of the arrow.
N Remove the carburetor box
cover (2).
Spark Arresting Screen in
Muffler
Spark Plug

Stihl MS 441 Specifications

General

Displacement	70.7 cc
Weight	6.6 kg
Fuel Capacity	0.78 L
Chain Oil Capacity	0.36 l
Oil Capacity	0.36 l
Oil tank volume	0.36 l
Chain pitch	3/8"
