Stihl MS 461 User Manual

MS 461 R
English
34
N Remove the filler cap.
Refueling
Take care not to spill fuel while fueling
and do not overfill the tank – leave
approx. 1/2" (13 mm) air space.
Closing
Handle is in an upright position:
N Position filler cap – markings on filler
cap and housing must align.
N Push the filler cap down as far as it
will go.
N Push the filler cap down and twist it
clockwise until it engages.
Then the markings on filler cap and
housing will align.
N Flip the handle down.
Filler cap is now closed.
If the filler cap will not engage into the
tank housing
The base of the filler cap is rotated in
relation to the upper part.
N Look at the black alignment marks
on the top of the filler cap.
001BA237 KN
001BA234 KN
001BA233 KN
001BA231 KN
001BA235 KN
Left: Base of filler cap is rotated –
interior marking (1) is aligned
with the exterior marking.
Right: Base of filler cap is in the cor
-
rect position – interior
marking is below the clip. It
does not align with the exte
-
rior marking.
001BA241 KN
1
001BA238 KN

Stihl MS 461 Specifications

General

Motor type	2-stroke motor
Chain gauge	1.6 mm
Chain pitch	3/8 \
Automatic oiling	Yes
Oil tank capacity	0.325 L
Fuel tank capacity	0.8 L
Engine displacement	76.5 cm³
Engine power	6 hp
Power source	Gasoline

Weight and Dimensions

Weight	6700 g
