Stihl MS 461 User Manual

MS 461 R
English
57
1 Carburetor Box Cover
2 Carburetor Adjusting Screws
3 Spark Plug Boot
4 Wrench Holder
5 Chain Brake
6 Chain Sprocket
7 Chain Sprocket Cover
8 Chain Tensioner
9 Bumper Spike
10 Guide Bar
11 Oilomatic Saw Chain
12 Chain Catcher
13 Splatter Shield
14 Oil Filler Cap
15 Muffler
16 Front Hand Guard
17 Front Handle (Handlebar)
18 Decompression Valve –
(Automatically Resetting)
19 Starter Grip
20 Fuel Filler Cap
21 Master Control Lever
22 Throttle Trigger
23 Rear Handle
24 Throttle Trigger Lockout
25 Rear Hand Guard
26 Depth Limiter
27 Star Knob
28 Bow Grip
# Serial Number
Main Parts
18
28
5
12
24
27
#
6
8
9
1
2
3
4
11
10
7
14
15
16
17
19
20
21
22
23
25
13
3443BA036 KN
26

Stihl MS 461 Specifications

General

Motor type	2-stroke motor
Chain gauge	1.6 mm
Chain pitch	3/8 \
Automatic oiling	Yes
Oil tank capacity	0.325 L
Fuel tank capacity	0.8 L
Engine displacement	76.5 cm³
Engine power	6 hp
Power source	Gasoline

Weight and Dimensions

Weight	6700 g
