Stihl MS241C-M User Manual

MS 241 C-M
English
29
Preparations
N Before fueling, clean the filler cap
and the area around it to ensure that
no dirt falls into the tank.
Always thoroughly shake the mixture in
the canister before fueling your
machine.
N Position the machine so that the
filler cap is facing up.
WARNING
In order to reduce the risk of fire and
other personal injury from escaping gas
vapor and fumes, remove the fuel filler
cap carefully so as to allow any pressure
build-up in the tank to release slowly
Opening
N Raise handle.
N Twist filler cap counterclockwise
(approx. 1/4 turn).
Markings on filler cap and housing must
align.
N Remove the filler cap.
Refueling
Take care not to spill fuel while fueling
and do not overfill the tank – leave
approx. 1/2" (13 mm) air space.
Closing
Handle is in an upright position:
N Position filler cap – markings on filler
cap and housing must align.
N Push the filler cap down as far as it
will go.
Fueling
001BA229 KN
001BA236 KN
001BA232 KN
001BA234 KN
001BA237 KN
001BA234 KN

Stihl MS241C-M Specifications

General

Weight	4.5 kg
Power-to-Weight Ratio	0.52 kW/kg
STIHL Oilomatic saw chain pitch	3/8" P
Power output	2.3 kW
Weight (without cutting equipment)	4.5 kg
Chain pitch	3/8" P
Recommended bar length	35-40 cm
Displacement	42.6 cm³
Chain Oil Capacity	0.20 l
Fuel tank volume	0.39 l
Chain oil tank volume	0.20 l
