Technical data 6
Technical data
1.5
Load
capacity
/Load
Q
(t)
1.4 1.4 1.6 1.8 2
1.6
Centre of
gravity
c
(mm)
600
1.8
Load
distance
from load
wheel
axle with
forks
raised
x
(mm)
914
1.9
Distance
between
axles
with
forks
raised
y
(mm)
1210 1275 1275 1342 1275 1342 1342
Weights
2.1
Tare
weight
(includ-
ing bat-
tery)
kg
306 289 401 465 401 465 465
2.2
Load
per axle
when
loaded
(front /
rear)
kg
596 /
1124
(8)
568 /
1121
(1)
705 /
1296
(2)
732 /
1334
(3)
754 /
1447
(2)
778 / 1487
(3)
825 /
1640
(3)
2.3
Load
per axle
when
empty
(front /
rear)
kg
242 /
64
(8)
224 /
65
(1)
312 /
89
(2)
358 / 107
(3)
312 / 89
(2)
358 / 107
(3)
358 /
107
(3)
Wheels, Chassis
3.1
Tyres Polyurethane
3.2
Front
wheel
dimen-
sions
mm
ø 230 x 75
/ ø 100 x 40
3.3
Rear
wheel
dimen-
sions
mm
ø 85 x100
45
