Still ECU-20 - Page 90

6 Technical data
Technical data
3.5
Wheels:
front
/rear
number
(x=drive
wheel)
1x - 2 / 2
3.6
Front
track
width
b
10
(mm)
458
3.7
Rear
track
width
b
11
(mm)
350 / 390 / 510
Dimensions
4.4Lift
h
3
(mm)
123
4.9
Tiller
height in
operat-
ing posi-
tion (min
/max)
h
14
(mm)
840 / 1240
4.15
Lowered
fork arms
height
h
13
(mm)
85
4.19
Total
length
I
1
(mm)
1595 1660 1660 1727 1660 1727 1727
4.20
Length
including
shoulder
of fork
arms
I
2
(mm)
445 510 510 577 510 577 577
4.21
Total
width
b
1
(mm)
720
4.22
Fork arm
dimen-
sions
s/e/l
(mm)
52 / 170 / 1150
(4)
4.25
External
fork arm
gauge
b
5
(mm)
520 / 560 / 680
4.32
Clear-
ance
at mid
wheel-
base
m
2
(mm)
36
84
