Operating and display elements
Three-way mini-lever
1
2
3
4
5
6
7
8
7325_003-026
1 "Lift mast" 36
0° lever
2 Function key
F1
3 Function ke
yF2
4 "Drive dir
ection/turn indicator" cross lever
5 Function key "
5th function"
6 "Auxiliary h
ydraulics 1" operating lever
7 "Auxiliary
hydraulics 2" operating lever
8 Signal hor
n button
NOTE
Depending on the equipment, various electric
attachment parts can be controlled via function
keys (2) and (3). Changes must only be made
bytheSTILLservicecentre.
