Installing the drain hose
Installation (Cont.)
WARNING!
• Do not kink or protract the drain hose.
• Position the drain hose properly in order to prevent water spillage onto the floor
and potential damage.
• Never immerse the end of the drain hose in water.
The drain hose is installed at the back of the machine. For drainage of the washing
water, you can install the other end of the hose three different ways, as illustrated:
• Lead the drain hose into a drain spout (Fig. 8).
• Affix the drain hose into a branch drain pipe of the laundry sink (Fig. 9).
• Lead the drain hose into a sink/basin, using the supplied drain hose support and
secure it with a rope or tie (Fig. 10). To ensure proper drainage when the washing
machine is in use, the height of the drain hose must not be higher than 100cm above
ground.
Fig. 8 Fig. 9
Drain
spout
WARNING!
• If the drain hose is too long, do not force it into the washing machine as it will
cause abnormal noise.
• Never lay down the drain hose, as water will be discharged.
• Be sure the drain hose is properly routed so it will not kink or lift off the sink.
Fig. 10
Basin
• When the washing machine is not in use, you may leave the drain hose at the back
of the machine, using the hose clips to keep it in place.
