UM2407 Rev 1 7/48
UM2407 Ordering information
47
2 Ordering information
To order the Nucleo-144 board corresponding to the targeted STM32, use the order code
given below in
Table 1:
2.1 Product marking
Evaluation tools marked as “ES” or “E” are not yet qualified and therefore not ready to be
used as reference design or in production. Any consequences deriving from such usage will
not be at ST charge. In no event, ST will be liable for any customer usage of these
engineering sample tools as reference design or in production.
“E” or “ES” marking examples of location:
• On the targeted STM32H7 that is soldered on the board (for illustration of STM32H7
marking, refer to the STM32H7 datasheet “Package information” paragraph at the
www.st.com website).
• Next to the evaluation tool ordering part number that is stuck or silk-screen printed on
the board.
These boards feature a specific STM32H7 device version which allows the operation of any
stack or library. This STM32H7 device shows a "U" marking option at the end of the
standard part number and is not available for sales.
2.2 Codification
The meaning of the codification is explained in Table 2.
Table 1. Ordering information
Order code Board reference Target STM32H7 Differentiating feature
NUCLEO-H743ZI
MB1364
STM32H743ZIT6U
– Ethernet
– USB OTG FS on
Micro.AB connector
–ST-LINK/V2-1
NUCLEO-H753ZI STM32H753ZIT6U
– Ethernet
– USB OTG FS on
Micro.AB connector
– STLINK-V3E
– Cryptography
Table 2. Codification explanation
NUCLEO-XXYYZTN Description Example: NUCLEO-H743ZI2
XX MCU series in STM32 Arm Cortex MCUs STM32H7 Series
YY MCU Product line in the series STM32H743
Z STM32 package pin count 144 pins
