- 37 -
Parts List
ITEM PART NO. DESCRIPTION QTY.
1 36099 Grounding Switch 1
2 55054 Decal Engine Stop 1
3 21930 Lead Ground 110 2
A * 6-32 X 1/4 Pan Head Screw 2
B * Lock Nut 1
* These parts not available separately, they come with the
grounding switch only.
The switch is a single pole single throw (SPST) normally open, momentary contact push button which grounds
out the ignition voltage when pressed. To stop the engine, depress the button and hold in until the engine comes
to a complete stop.
Periodically inspect the grounding switch and associated wiring to make sure the system is operating properly.
Make sure that there are no loose connections or bare / broken wires. Also make sure that the grounding switch
wires are fastened securely out of the way of hot exhaust and engine parts, moving drive components, and pinch
points.
65CM, 75CM, 95CM, 105CM
Grounding Switch
