FIGURE 1: OPTAC DOWNLOAD TOOL OUTLINE
USB
Connector
Smart Card Slot
VU
Connector
Download
Indicators
Smartcard Download
button
Full tachograph
download button
Partial tachograph
download button
On/Off/Programmable
function button
Battery life
Indicator
