ATTENTION ELECTRICIAN!!
To prevent condensation from forming inside, all penetrations with electrical conduit must be
sealed internally where it enters cold space and externally (see figure below). Wall or ceiling
penetrations must not interfere with panel seams or locking devices (see figure below).
REQUIERED ELECTRICAL AND CONNECTIONS
COOLERS WITH ONE 15K BTUs AIR CONDITIONER OR SMALLER
A dedicated 120V 15-amp circuit required
• The electrician will have to install:
o One 120V surface mount outlet box to plug in the CoolBot Controller and the A/C,
inside the cooler - on the right side of the A/C.
o One 120V supply via conduit to the front light atop the door to provide power to the
light and the factory pre-wired light switch (see page 34).
• A/C plug configuration (10K, 12K & 15K BTU):
