FRAME GROUP (100 PSI)
STORMCHASER 86038660 03/16/09
5-4
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86201290 280-02 2 RIVET AL. 3/16 X 1/2 CLOSED
2 86201500 260-71 1 SOLUTION COVER D/B
3 86002450 22015 1 COUPLER, 1/4 OD
4 86005590 56014 1 NIPPLE, 1/4 CLOSE
5 86197350 22014 1 COUPLER, 1/4F HEX
6 86091260 87217 1 WASHER, 9/16 ID BENT
7 86201590 290-08 1 SOL. SCREEN (ACORN) W/RUB BASE
8 86210210 70162 4 SCR, 10-32 X 3/8 PPHMS SS
9 86198460 20008 1 CLAMP, 5/8 NYLON UL/CSA
10 86090710 010-02 1 AXLE ASM, RIGHT
11 86200020 41393 1 HINGE, ACCES PANEL
12 86240430 40083 1 HOSEBARB, 3/8MT X 3/8 NYLON
13 86006620 70127 4 SCR, 6-32 X 1/4 PPHMS SS
14 86271350 57187 4 NUT, 6-32 ACORN, ZINC
15 86010630 87013 4 WASHER, 1/4 X 5/8 OD SS
16 86273830 70020 8 SCR, 1/4-20 X 1/2 HHCS SS
17 86271380 57196 2 NUT, 1/2 PUSH-ON DOME CAP
18 86202250 040-06 2 WHEEL 8” BLK CENTERED HUB
19 86090700 010-01 1 AXLE ASM, LEFT
20 86199430 040-03 2 CASTER SWIVEL 4”
21 86033430 75335 1 TANK, SOLUTION DB BLK 100 PSI
22 86200630 500350 1 LABEL, STORMCHASER MAIN
23 86202240 390-24 2 WASHER, 1/4 X 5/8 BONDED NEOPRN
24 86276270 70619 1 SCR, 1/4-20 X 2.0 HHMS SS F/T
25 86232790 27912 1 CHAIN ASM, #10 BEAD S/S W/EYES
26 86242130 48100 1 KNOB, HEX PRESS LOC WING
27 86270900 57037 1 NUT, 1/4-20 WING SS NOT SHOWN
28 86323840 - 2 WHEEL, 12”
29 86091430 05253 1 AXLE ASSEMBLY D.B. 1000137325
30 86079100 620065 2 PLATE AXLE 1000137325
31 86070910 140758 1 BRKT 12” WHEEL MNT BRACE 1000137325
32 86005710 57105 1 NUT, 1/4 -20 HEX W/STAR WASHER
33 86020310 70015 5 SCR, 1/4-20 X 3/4 HHCS SS NP
34 86010710 87080 4 WASHER, .5 X 1.25 FLAT GR8 PLT
35 86323860 - 4 BUSHING FLANGE .501D X .630D
