FRAME GROUP (200 PSI)
STORMCHASER 86038660 03/29/07
5-6
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86201290 280-02 2 RIVET AL. 3/16 X 1/2 CLOSED
2 86201500 260-71 1 SOLUTION COVER D/B
3 86002450 22015 1 COUPLER, 1/4 OD
4 86005590 56014 1 NIPPLE, 1/4 CLOSE
5 86199580 250-35 1 D/B BPR 200PSI
6 86200250 151-50B 1 HOSE, 42” GRY3/8 1/4MPTXCUT
7 86091260 87217 1 WASHER, 9/16OD BENT
8 86201590 290-08 1 SOL SCREEN (ACORN) W/RUB BASE
9 86090710 010-02 1 AXLE ASM, RIGHT
10 86200020 41393 1 HINGE, ACCESS PANEL
11 86240430 40083 1 HOSEBARB, 3/8MT X 3/8 NYLON
12 86274290 70162 4 SCR, 10-32 X 3/8 PPHMS SS
13 86006620 70127 3 SCR, 6-32 X 1/4 PPHMS SS
14 86271350 57187 4 NUT, 6-32 ACORN ZINC
15 86010630 87013 8 WASHER, 1/4ID X 5/8OD SS
16 86020360 70020 17 SCR, 1/4-20 X 1/2 HHCS SS
17 86090700 010-01 1 AXLE ASM, LEFT
18 86202250 040-06 2 WHEEL 8” BLK CENTERED HUB
19 86202250 57196 2 NUT, 1/2 PUSH-ON DOME CAP
20 86198460 20008 1 CLAMP, 5/8 NYLON UL/CSA
21 86099840 065-28 1 DIAMONDBACK 200 PUMP SUPPORT
22 86199430 040-03 2 CASTER SWIVEL 4” SWIVEL
23 86033440 75336 1 TANK, SOLUTION DB BLK 200 PSI
24 86200630 500350 1 LABEL, STORMCHASER MAIN
25 86202240 390-24 2 WASHER 1/4 X 5/8 BONDED NEOPRN
26 86276270 70619 1 SCR, 1/4-20 X 2.0 HHMS SS F/T
27 86232790 27912 1 CHAIN ASM, #10 BEAD SS W/EYES
28 86242130 48100 1 KNOB, HEX PRESS LOC WING
29 86270900 57037 1 NUT, 1/4-20 WING SS NOT SHOWN
30 86202280 89252 2 WHEEL, 12” BLK CNTRD HUB 1000137325
31 86091430 05253 1 AXLE ASSEMBLY D.B. 1000137325
32 86079100 620065 2 PLATE AXLE 1000137325
33 86070910 140758 1 BRKT 12” WHEEL MNT BRACE 1000137325
34 86005710 57105 2 NUT, 1/4 -20 HEX W/STAR WASHER
35 86273780 70015 4 SCR, 1/4-20 X 3/4 HHCS SS NP
36 86006850 70393 1 SET SCR, 1/4-20 X 1.25
37 86271370 57189 1 NUT, 1/4-20 FLANGE LOCK
38 86010710 87080 2 WASHER, .5 X 1.25 FLAT GR8 PLT
To Next Page
