Tension adjustment
of the door spring
【】Figure 5
Tension adjustment of the door spring
●
Connection of drain hoses
●
Th e do or s pri ngs ar e se t at the f actor y to th e pr ope r ten si on f or th e o ute r do or. If a est het ic
wooden panel are installed, you will have to adjust the door spring tension. Rotate
the adjusting screw to drive the adjustor to strain or relax the steel cable(see figure 5).
D oo r sp ri ng ten sio n is c o rre ct wh en
the door remains horizontal in the
fully o pened position yet rises
toaclosewiththeslightliftofa
finger.
，
rel ax
PLEASE HANG UP THE DRAIN HOSE EITHER WAY OFA, B, C
φ
40mm
A
B
C
Counter
Front
Drain pipe
Drain hosehook
Close the drain hose hook to the counter
Inse rtthe drainh ose into a dra in pi pe with a m inimum diameter of 4cm, or l et it r uninto the s ink, making sure to
avoid bendingor crimping it. Use the special plasticsuppo rt thatcomes with the appliance . The top ofthe ho se
must be at a heig ht b etwe en 40 an d 1 00cm .The f ree e nd o f t he hose must n ot b e im mer sed in wa ter to a void the
back f lo w of it.
