STRASBAUGH, INC.
August 11, 1995 6DS-SP Ver 4.15 Page 5
Support for a Four Lamp Light Tower:
Calibration/configuration variable 98, "Light tower config. (0, 1)"
(If a light tower is not installed, variable 98 can be set to either "0" or "1".)
If set to "0", the original three light tower is supported.
If set to "1", a four light tower is supported as follows:
Light on Light blink Light off
Red Maint Alarm No maint or alarm
Yellow Cycle halted A port empty All ports filled
(cassette not
physically present
or cassette ready
to be removed)
Green Processing Idle (never)
(In a cycle
running or halted)
Blue SECS on-line (never) SECS off-line
Notes:
More than one light can be on at a time. Also, if multiple conditions for a light occur,
blinking has priority.
The amber light will blink:
If any cassette has its arm raised.
If a cassette has its arm lowered but its status has changed from "active" to
"inactive" (such as a send cassette becoming completely emptied or a receive
cassette becoming completely filled).
