Operations Model 6DS-SP Planarizer
3 - 88 Version 4.0 - February 1998
CARRIER UNLOADING FOR THE TWO-TABLE
MACHINE
WARNING: Always follow the procedure below to remove
carriers from spindles. To prevent damage to table
and spindles, DO NOT allow spindles to drop onto
table.
Tools Required
• carrier load fixture (Symix # 274559)
Procedure
1. Close all doors to the machine.
Select the Auto Polish Cycle Menu:
Operator Action Explanation/Screen Display
2. <F9> Press the F9 key to choose
“Select Menu”.
3. <F1> Display the Auto Polish Cycle
Menu by pressing the F1 key to
select “Auto Cycle”.
Screen displays the Auto Polish
Cycle Menu.
To Next Page
