Operations Model 6DS-SP Planarizer
5 - 62 Version 4.0 - February 1998
“LT SEND ELEV NOT ARRIVING AT SLOT - # 164
“RT SEND ELEV NOT ARRIVING AT SLOT - # 165
“LT RECV ELEV NOT ARRIVING AT SLOT - # 166
“RT RECV ELEV NOT ARRIVING AT SLOT - # 167
Problem
Indicator
Problem
Location
Component/ Cause
Resolution
ERROR
MESSAGE
Control
Computer
Screen
(1) Elevator servo
not arriving at the
commanded
position.
(1a) Servo tripped out-
- Open and close polish
section operator doors
to reset.
OPERATIONS
“BRIDGE NOT ARRIVING AT LOAD - # 168
“BRIDGE NOT ARRIVING AT MIDDLE - # 169
“BRIDGE NOT ARRIVING AT TABLE 1 - # 170
Problem
Indicator
Problem
Location
Component/ Cause
Resolution
ERROR
MESSAGE
Control
Computer
Screen
(1) Bridge servo not
arriving at the
commanded
position.
(2) Calibration
variable out of
range.
(1a) Servo tripped out--
Open and close polish
section operator doors
to reset.
(2a) Abort and rehome
axis.
OPERATIONS
