THREE-PANEL ALERT GRAPHICS
The three-panel alert graphics used in the 6DS-SP manuals are composed of
a keyword; a hazard symbol; and a text box identifying the hazard, the
result(s) of ignoring the hazard, and instructions on avoiding the hazard.
Each alert graphic hazard symbol used in the 6DS-SP Operations and
Maintenance manuals is presented below, together with information on
when to be aware of the hazard. Note that text box information may change
as is appropriate to most precisely identify specific hazards and provide
avoidance instructions.
Alert Graphic:
Symbol:
• pinch points
When to be Aware:
• whenever machine parts are moving.
• anytime immediately before and during auto mode operation.
• anytime immediately before and during manual operation.
• Note that components may continue to move briefly after the cycle is completed
.
