Maintenance Model 6DS-SP Planarizer
2 - 12 U Version 4.0 - February 1998; Update 11/06/01
STEP 6 - CONNECTING UTILITIES
Related Engineering Drawings
• 217946A1
Rear View
Note: Engineering drawing 217946A2 is an accurate layout of the rear of a
standard
configuration 6DS-SP showing utility connections and
plumbing.
Assuming a standard machine configuration, Figure 2-1 and 2-2, below, is a
simplified expanded view of the rear of the machine illustrating the location of
utility connections and plumbing. The subsections that follow the figure detail
procedures for completing the connections.
