Strasbaugh 6DS-SP - Page 409

Strasbaugh Installation
Version 4.0 - February 1998; Update 11/06/01 2 - 13 U
Figure 2-1 Utility Connections - Standard Configuration
1 Main Machine Circuit Breaker
2 Door Handle
3 Compressed Air Supply
4 110 VAC Quad Outlet
5 Exhaust
6 Slurry 1 Supply
7 Slurry 2 Supply
8 Utilities Cluster (see Figure 2-2 for details)
8 7 6 5
1
2
3
4
