Maintenance Model 6DS-SP Planarizer
3 - 10 Version 4.0 - February 1998
Figure 3-4 Planarizer Rear View
19
20 20
21 22
23
24
19 Left Side Electrical Cabinet Service Door
20 Right Side Electrical Cabinet Service Doors
21 Rear Door Emergency Off Button
22 Rear Door Power On Lamp
23 Rear Electrical Enclosure Door Handle
24 Main Power Supply Circuit Breaker
