Maintenance Model 6DS-SP Planarizer
9 - 52 Version 4.0 - February 1998
CLEANING STATION ALIGNMENT
[#1 IN CLEANING STATIONS ADJUSTMENT SERIES]
Notes:
The procedure below centers the cleaning stations under the spindles.
CAUTION: Be sure to perform the Bridge Load Position
Calibration procedures in the Software Calibration
Procedures chapter of this manual BEFORE beginning
the cleaning station alignment procedures below.
LEFT CLEANING STATION
A. BEFORE YOU BEGIN
Tools Required
• 9/16-in. socket wrench
• precision scale (accurate to .03125 in.)
