Maintenance Model 6DS-SP Planarizer
9 - 82 Version 4.0 - February 1998
ROBOT BELT TENSIONING
[#B IN ELEVATORS AND ROBOT ADJUSTMENT SERIES]
A. BEFORE YOU BEGIN
Tools Required
• flat blade screwdriver
• 5/16-in. open end wrench
• 7/32-in. hex key
Close All Access Doors
Turn Machine Power On, Perform Home Sequence Routine
Follow the procedures detailed in the Operator Functions chapter of the 6DS-SP
Operations manual.
B. CHECK AND ADJUST THE BELT TENSION
1. At Page 1 of the Manual Control Menu, select Robot Move and choose
Left Send move the robot to the left send elevator.
