Strasbaugh Mechanical Maintenance Procedures
Version 4.0 - February 1998 9 - 91
SHUTTLE
SHUTTLE TRAVEL ADJUSTMENTS
SHUTTLE FORWARD STOP AND REED SWITCH
ADJUSTMENT
A. BEFORE YOU BEGIN
Tools Required
• precision scale (accurate to .03125 in.)
• 9/16-in. open end wrench
• 9/16-in. socket wrench
• 1 1/8-in. open end wrench
• flat blade screwdriver
• straight edge
• 3/16 in. hex key
To Next Page
