Strasbaugh Software Calibration Procedures
Version 4.0 - February 1998 10 - 23
FUNCTION KEY CHOICES AVAILABLE AT THE DIAGNOSTICS
MENU
Key Label Function(s)
View
Inputs
"View Inputs" displays a page of 16 inputs. "Next Page" can be
used to scroll through the pages. (There are 4 pages of inputs.)
View
Outpts
"View Outputs" displays a page of 16 outputs. "Next Page" can be
used to scroll through the
pages. (There are 5 pages of outputs.)
View
Flags
"View Flags" displays a page of 16 flags. "Next Page" can be used
to scroll through the
pages. (There are 16 pages of flags.)
View
Ctrs
"View Counters" displays a page of 16 counters. "Next Page" can
be used to scroll through
the pages. (There are 4 pages of
counters.)
Counters 1 through 16 relate to analog input/output modules 1
through 16.
Counters 51 through 58 relate to analog input/output modules 17
through 24.
Next
Page
"Next Page" causes whatever type of item is currently viewed to
advance to the next page. If
already on the last page, will "wrap"
to the first page.
Toggle
Outpt
"Toggle Output" permits toggling any output. When selected, the
prompt line will ask for an
output number. When the number is
entered, that output is toggled.
Toggle
Flag
"Toggle Flag" permits toggling any flag. When selected, the
prompt line will ask for a flag
number. When the number is
entered, that flag is toggled.
Change
Ctr
"Change Counter" permits changing any counter. When selected,
the prompt line will first
ask for a counter number. After the
counter number is entered, the prompt line will ask for a
value for that counter. When the value is entered, the counter is
changed.
Note: Certain changes are not realistic. For example, it is not realistic to
change any counter associated with physical analog inputs. Also, some
outputs and flags are continuously controlled by software and, if
changed, will immediately change back to what they were.
