Maintenance Model 6DS-SP Planarizer
10 - 128 Version 4.0 - February 1998
3. At the Calibration/Configuration Menu, enter the new calibration value
for variable 66, Left back pressure offset, in psig.
Example: -.4
4. Check the new adjustment by reading the status screen display for left
spindle back pressure:
GOAL: The back pressure status screen value should equal 14.7
psia.
a. If the status screen back pressure value displayed in psia does not
meet the goal, repeat the correction procedure until the goal is met.
b. If the status screen value meets the goal, skip to Section D., below.
C. CORRECTION FOR BACK PRESSURE DISPLAYED IN PSIG
1. At the Calibration/Configuration Menu, read the current value of
variable 66, Left back pressure offset.
(Variable 68 = Right back pressure offset.)
Example: 0.4
