Strasbaugh Pneumatic Adjustments
Version 4.0 - February 1998 11 - 17
B. CHECK CURRENT ADJUSTMENT
1. Observe motion while raising and lowering the conditioning arm:
Note: Raising the arm also raises the device.
a. At Page 2 of the Manual Control Menu, select Cond Arm Up/Dn
and choose Up to raise the arm.
b. Select Cond Arm Up/Dn and choose Down to lower the arm.
c. Note the arm motion:
GOAL: Upward and downward movement should be smooth.
If the goal is not met, correct the motion by following the
procedures in Section C., immediately below.
If the goal is met, skip to When Satisfactory Adjustment Is
Achieved, below.
C. ADJUSTMENT PROCEDURE
1. Turn the machine power to OFF by pressing the red <EMERG OFF>
button located on the control panel.
2. Remove the Right Front Service Door.
3. Locate the small air cylinder mounted at the end of the conditioning
arm.
4. Find the two adjustment knobs of the in-line flow controls.
5. Rotate each adjustment knob fully counterclockwise.
6. Replace door(s).
