Maintenance Model 6DS-SP Planarizer
11 - 34 Version 4.0 - February 1998
2. Read the Left and Right Spindle Blow Off gauges located on the panel
inside the Left Front Service Door.
3. Unlock the red locking rings:
Pull out on the red locking rings surrounding the adjustment knobs.
4. Find the black button on the coil of Solenoid 11 on the valve panel.
Using a screwdriver, push up on the button to activate.
5. While pressing up on the Solenoid 11 button, set the Left Spindle Blow
Off adjustment knob to 5 to 10 LBS.
6. While pressing up on the Solenoid 11 button, set the Right Spindle
Blow Off adjustment knob to 5 to 10 LBS.
7. Release the coil button of Solenoid 11.
8. Push the red locking rings back in.
9. Replace the service door.
