Maintenance Model 6DS-SP Planarizer
13 - 44 Version 4.0 - February 1998
“AXIS 1 SERVO AMPLIFIER FAULT” - # 57
(LEFT SPINDLE)
“AXIS 2 SERVO AMPLIFIER FAULT”- # 58
(RIGHT SPINDLE)
“AXIS 3 SERVO AMPLIFIER FAULT” - #59
(BRIDGE TRAVEL)
“AXIS 4 SERVO AMPLIFIER FAULT” - #60
(TABLE)
Problem
Indicator
Problem
Location
Component/ Cause
Resolution
ERROR
MESSAGE
Control
Computer
Screen
Left Spindle
or
Right Spindle
or
Bridge Travel
or
Table
(1) Polish section
door not securely
latched.
(2) Output error.
(3) Amplifier fuse.
(4) Loose wiring.
(5) Motor over-
temperature.
(1a) Open and close
door to attempt to
reset; restart.
(2a) Power down entire
machine and restart to
see if problem
continues.
OPERATIONS
(3a) Test amplifier
fuse; replace if
needed.
(4a) Check for loose
wiring and correct.
(5a) Check for motor
over-temperature.
Refer to schematics for
associated parts.
MAINTENANCE
