Strasbaugh Machine Description
Version 4.0 - February 1998 2 - 39
After making the electrical supply connection, leave the main power
disconnect (main machine circuit breaker) in the "OFF" condition by moving
the lever to its down position; close the electrical cabinet enclosure door and
latch assembly tightly.
The 110 VAC quad outlet (7) is an AC convenience outlet.
COMPRESSED AIR
The compressed air preparation system is mounted on the rear of the
machine and clearly labeled. The compressed air supply (1) should be
connected to the supply connector on the left end of the air preparation
assembly. The supply should be flexible tubing designed to accommodate
the specified flow and pressure.
VACUUM AND D.I. WATER
The connections for vacuum (5), D.I. water (10), and D. I. water return
(10a) are located near the center of the machine cabinet and clearly labeled.
A bulkhead fitting is provided for each system to be connected to flexible
tubing. The tubing should be selected to provide the necessary flow and
pressure for the machine.
VACUUM SYSTEM
Related Engineering Drawings
• 218907A1
Vacuum System
• 218907A2
Vacuum System
• 218907E1
Vacuum System
• Manufacturer’s
Data
ITT Pneumotive Pump, Motion Industries
