Using the menus
Application Fan Htg Stg 1 Htg Stg 2 Mod Htg Clg Stg 1 Clg Stg 2 Clg Stg 3 Clg Stg 4 Rev Valve Econ Mod CO2
Dehumid
Stg
Humidifier
Stg
Humidifier
Mod
RT 2STG
RTU X X X X X
RT ECON
RTU X X X X X X
HP 2STG
Heatpump X X X X X X
RT IAQ
RTU X X X X X X X
RT MOD
RTU X X X X X
HP DEH
Heatpump X X X X X
HUM
-DEH RTU X X X X X X X
RT 3STG
RTU X X X X X X X
RT 4STG
RTU X X X X X X X X
HP 3STG
Heatpump X X X X X X
HP 4STG
Heatpump X X X X X X X
Custom
Object
Instance
MSV 127
To customize any configuration including using the CO2 DVC or Enthalpy Economization, you must access those through writing to the BACnet points-
Please note: MSV, 7, 8, 9, 10, 16, 17, 18, 19, 23, 27, 28, 30, 32, 44, 45, 46, 48, 49 52, 54, 55, 65 & 68 are used for ‘’custom’’ configuration applications.
Make sure MSV127 is set to ‘’custom’’ BEFORE setting any of those MSV’s
Setup menus (quick setup)
Table
