STRATO BW437-RTU - Multi-State Values

Multi-State Values
Please note that objects tagged as:
• Cfg: represent configuration properties of the device that are typically only set once during commissioning and start-up
• User: represent properties or objects that are typically manipulated by users of the controller
• Status: represent objects or properties that are ‘’typically’’ meant to be displayed on graphics for various required visualization
• Cmd: represent objects that can be controlled directly by other BACnet external process
Object
Instance
RTU
Object name
Description
Tags
Default value State texts
MSV1
CFGSens Remote thermistor 10K Cfg Type 3 Type 3
Type 2
MSV2
AI_RS Select room temperature input Cfg Intern Intern
AI-1
AI_2
AI-3
AI-4
MSV3
MODE System mode User On Off
Auto
Cool
Heat
MSV4
FAN Set fan mode User Auto On
Auto
MSV5
Eff_Occ Effective occupancy mode Status --- Occupied
Unoccup
TempOcc
Standby
MSV6
Loc-Occ Occupancy command User Loc-Occ Loc_Occ
Occupied
Unoccup
