1. PRODUCT CHARACTERISTICS
1.1. OVERVIEW
Streamax M3-H0401 is a functional Mobile Digital Video Recorder specially designed for vehicle
video surveillance and remote monitoring. It has a high-speed processor and embedded operating
system, combining with the most advanced H.264 video compression / decompression technology,
3G/4G network, GPS positioning technology, as well as WIFI. It supports not only video recording in
1082P, 720P, AHD, D1, HD1 and CIF formats, but also vehicle travel information recording and wireless
data upload. With center software it also achieves alarm linkage central monitoring, remote management
and playback analysis. It is easy to use with simple design, multi-functions, SSD + SD card or dual SD
cards, superior anti-vibration, flexible installation and high reliability.
1.2. SPECIFICATIONS
Function Overview
Preview, Recording, Playback, Network, Locating
System
OS
Linux 3.0.8
Control Mode
Easy Check, network (3G/4G/WIFI), mouse, CP4
Video
Input
4 channels AHD+1 channel 1080P
Output
1 channel
Total Resource
PAL: (4x25)FPS 720P(AHD)+1080P@30FPS(IPC)
or (4x12)FPS 1080P(AHD)+1080P@30FPS(IPC)
NTSC: (4x30)FPS 720P(AHD)+1080P@30FPS(IPC)
or (4x15)FPS 1080P(AHD)+1080P@30FPS(IPC)
Video Signal
Standard
Electrical level: 1Vpp Impedance : 75Ω NTSC/PAL Optional
Audio
Input
5channels (1 channel IPC audio input)
Output
1channel
Audio Signal
Standard
Electrical level: 2Vpp Input impedance: 4.7kΩ
Display
Display Split
1/4/9
OSD
GPS information, alarm, license plate, speed, date/time
Operation Interface
Semi-transparent GUI
Recording
Video/Audio
Compression
Video: H.264
Audio: ADPCM, G.711A, G.711U
Image Resolution
Analog:
PAL: 720P(1280X720), WD1(928X576), WHD1(928X288),
WCIF(464X288), D1(704X576), HD1(704x288),
CIF(352x288);
NTSC: 720P(1280X720), WD1(928X480),
WHD1(928X240), WCIF(464X240), D1(704x480),
HD1(704x240), CIF(352x240);
