StreamLight LITEBOX - Appendix IV, SL- 40 X Replacement Parts and Diagram

SL - 40 REPLACEMENT PARTS
ITEM QTY PART NO. ITEM QTY PART NO. DESCRIPTION
1
1
40107 KIT, P
A
R 36 LAMP RETROFIT
16
1
400176 PLUG ASSY.- 4 PIN P.F.
(LAMP RING & SPACERS) 400175 PLUG ASSY - 2 PIN STANDARD
40117 KIT, PAR 36 LAMP RETROFIT, BEIGE 17 1 900079 L.E.D.
2
1
45908 LAMP, 8W FLOOD 18 1 400241 P.C.B. ASSY.- STANDARD
45911 LAMP, 8W SPOT 400242 P.C.B. ASSY. - POWER FAILURE
45910 LAMP, 20W FLOOD 19 1 45070 RACK ASSY - STANDARD, ORG
45913 LAMP, 20W SPOT 45071 RACK ASSY-DIRECT WIRE, ORG
3
3
40114 NEOPRENE SPACER
(
LAMP
)
40072 RACK ASSY-P.F., ORANGE
4
1
400105 LAMP HOUSING, ORANGE 40073 RACK ASSY - P.F. BEIGE
400105-1 LAMP HOUSING, BEIGE
5
2
202027 STRAIN RELIEF NOT SHOWN 40232 SHOULDER STRAP
(
W/D-RINGS
)
6
1
4051 SWIVEL HEAD ATT- ORANGE 400262 D-RINGS, SHOULDER STRAP
4052 SWIVEL HEAD ATT.- BEIGE 400267 SCREW PACKET,
(
REAR COVER
)
7
1
400130-1 SWITCH BOOT 400266 SCREW PACKET, BODY
8
1
400157 SWITCH W/BOOT 400307 FUSIBLE LINK ASSY
9
1
400258 REAR COVER,ORANGE
(
W/FOOT
)
400179 KIT, 2-PIN PLUG
(
INCLUDES
400258-1 REAR COVER,BIEGE
(
W/FOOT
)
PARTS FOR RACK AND LIGHT
)
10
1
400254 BODY R.H. - ORANGE
400256 BODY R.H. - BEIGE CHARGERS 22311 120V AC, STANDARD
11
1
400255 BODY L.H. - ORANGE 21725 230V AC, STANDARD
400257 BODY L.H. - BEIGE 22051 12V DC-1, W/LIGHTER ADAPTER
12
1
400174 DOOR, SOLID - ORANGE
400126 DOOR, SLIDING - ORANGE MISC. RACK 400170 STRAIN RELIEF
(
DIRECT WIRE
)
400126-1 DOOR, SLIDING - BEIGE PARTS 40163 LOCK, KEYED DIFFERENTLY
13
1
400123 NEOPRENE FOOT
(
INSTALLED
)
14
1
45937 BATTERY 40164 LOCK, KEYED ALIKE
15
1
400167 COILED CORD ASSY.
(
INSTALLED
)
30
The lead acid battery in this product is recyclable. At the end of its useful life, under various state laws,
it may be illegal to dispose of this battery in the municipal solid waste stream. Check with your local solid
waste officials for details in your area for recycling options or proper disposal.
Pb
