Fig 5
Fig 6
Fig 8 Fig 9 Fig 10
Fig 7
5. Ensure the headrest bars are properly
in place inside the bracket.
See figure 5.
6. Then, close and secure both brackets. See figure 6 & 7.
7. Once the guard has been secured to the headrests, then adjust the ceiling suction
mounts on both sides of the guard. See figure 8
8. Then adjust the position of the bars. To do so, you need to unclip the bracket that is
holding the bars (see figure 9 below) on both sides and position the bars accordingly.
Secure by clipping the bracket in place on both sides.
9. Once you are happy with the position of your bars, then adjust the width of each of
the bars. See figure 10 below.
