Strobel 141-23EV - Brief Setting Instructions

10 MA_141_142_A10-6-7-3-6-5_130617_en
2.5 Brief setting instructions
Setting data
Class
141-23EV
141-30
141-40
141-50
142-30
142-30N
142-40
A
Stitch length
3 - 6.5
3 - 6
0.7 - 2.7
0.6 -2.5
2.3 – 5.3
1 - 4
B
Stroke of loop
4.7
4.5 - 5
3.5
3.5
4.2
4.5
C
Needle point front
measured from cup
edge
22.6 20.5 18.5 16.8 18.8 17
L
Looper height
inclusive shaft
37 30.5 31.5 30.8 28.3 31
H
Looper front position
measured from cup
edge
11.5 8.2 7.5 5.5 11.5 9.7
K
Looper movement
9.5
9
5.3
4.8
8.2
6.7
H + J Total looper travel 17.7 12.7 11 10.1 12.5 11.3
F
Looper movement to
the right from needle
center to looper point
5.5 3 4.2 3.2 2.8 5.9
The clearence between the feed cups amount 12 – 14 mm.
