18 MA_VEB100-1-2-2W-4-5_A3-1_190627_en.doc
2.5 Brief setting instruction
2.5.1 Class VEB100-1, -2, -2W
41.3 mm
41.33 +0.02 mm
41.30 ±0.01 mm
41.40 +0.05 mm
1.5 +0.5 mm
4 ±0.5 mm
approx. 15°
18 +0.5 mm
Feed plate
left
12 N
right
12 N
140 N (meas. at plunger shaft)
6 N
approx. 5 - 8 mm
plates
approx. 13 mm
approx. 10 mm
2.8 +0.3 mm
2 4 stitches
